Sfera ShUO 1200×1500×400 IP54 cabinet

Equipment

• Galvanised steel body with polymer powder coating
• Thermal insulation – mineral wool 50 mm
• Door with a gasket around the perimeter and a lock
• Heater with thermostat
• Mounting panel / DIN rail
• Cable glands
• Mounting hardware kit

Basic configuration. The composition and dimensions are specified for the task – the cabinet is made to order.

Area of application

The dimensions of 1200×1500×400 mm allow several groups of circuit breakers, contactors, terminal blocks, metering devices and controllers to be placed on the mounting panel and DIN rails without a dense layout. This format suits nodes where equipment of one functional purpose is assembled in one body rather than spread across several cabinets.

Outdoor installation is made possible by 50 mm mineral wool thermal insulation and built-in heating with a thermostat, and the cable glands allow several cable lines to be brought in without breaking the seal. The wall mounting is convenient for installation on building walls, posts and steel structures where the cabinet cannot be sunk into a foundation.

Where it is used:

• electricity metering points at facilities with outdoor placement of panel equipment;
• distribution points of outdoor lighting systems;
• automation panels of pumping stations and utility networks;
• control cabinets for ventilation and refrigeration equipment on open sites;
• telecommunication and low-current communication nodes outdoors;
• distribution cabinets of production sites with outdoor placement of equipment.
