Sfera ShU 900×900×400 IP54 cabinet

Name: Sfera ShU 900×900×400 IP54 cabinet
Brand: Сфера
SKU: 1714

Sfera ShU 900×900×400 IP54 cabinet Photo 1

Characteristics

The compact body with a square base of 900×900 mm and a depth of 400 mm is designed to house medium-configuration equipment installed outdoors. Mineral wool 50 mm thick and IP54 protection keep the electrics safe from dust, moisture and temperature changes without having to choose a larger version. The wall mounting lets the cabinet be installed on a wall, post or steel structure, saving space on the site.

Catalog download

Description

Part number (design documentation code)	ShU482
Overall dimensions (height × width × depth), mm	900×900×400
Type	Insulated outdoor cabinet (ShU)
Body material	Galvanised steel
Thermal insulation material	Mineral wool (50 mm thick)
Degree of protection	IP54
Mounting	Wall-mounted

Equipment

Galvanised steel body with polymer powder coating
Thermal insulation – mineral wool 50 mm
Door with a gasket around the perimeter and a lock
Mounting panel / DIN rail
Cable glands
Mounting hardware kit

Basic configuration. The composition and dimensions are specified for the task – the cabinet is made to order.

Area of application

The 900×900×400 mm dimensions allow several groups of circuit breakers, contactors, terminal blocks, metering devices and small-automation controllers to be placed on the mounting panel and DIN rail. The insulated body with 50 mm mineral wool and a gasket around the door perimeter suits installation outside heated premises, where equipment is exposed to precipitation and temperature fluctuations. The cable glands provide organised and protected entry of power and low-current cables.

The ShU482 format is convenient where more capacity than a wall-mounted box is needed but a full-size floor-standing cabinet is too large for the area. The wall mounting and moderate depth of 400 mm allow the body to be installed on posts, building walls and steel frames without a separate foundation.

Where it is used:

outdoor power distribution points at utility facilities;
housing automation and metering at transformer substations and packaged substations;
control panels for lighting of streets, courtyards and car parks;
communication nodes and low-current systems on posts and building facades;
monitoring and automation cabinets of water supply and sewage systems;
distribution points at industrial sites and warehouse complexes.
