Sfera ShU 520×730×630 IP54 cabinet

Equipment

• Galvanised steel body with polymer powder coating
• Thermal insulation – mineral wool 50 mm
• Door with a gasket around the perimeter and a lock
• Mounting panel / DIN rail
• Cable glands
• Mounting hardware kit

Basic configuration. The composition and dimensions are specified for the task – the cabinet is made to order.

Area of application

The dimensions of 520×730×630 mm allow an automation panel, several modular devices on a DIN rail, terminal blocks and metering devices to be placed inside the cabinet and, if necessary, a compact power supply or controller. The width of 730 mm makes it possible to arrange the equipment in one or two rows, leaving room for glands and cable routing without bending the cables.

This version suits installation on open sites, posts, building facades and steel structures, where protection from dust and moisture matters, and where the units must keep working through changes in outdoor temperature thanks to thermal insulation. The wall mounting method and small dimensions simplify installation in places with limited space and make it possible to install the cabinet without a foundation or pedestal.

Where it is used:

• electricity metering points at service entrances of buildings and structures;
• lighting control panels on streets, courtyards and car parks;
• housing communication and low-current system equipment on posts and facades;
• automation cabinets for utility networks and low-power pumping stations;
• distribution points at construction sites and temporary sites;
• housing instrumentation on industrial territories.
