Sfera ShU 1800×1100×600 IP54 cabinet

Equipment

• Galvanised steel body with polymer powder coating
• Thermal insulation – mineral wool 50 mm
• Door with a gasket around the perimeter and a lock
• Mounting panel / DIN rail
• Cable glands
• Mounting hardware kit

Basic configuration. The composition and dimensions are specified for the task – the cabinet is made to order.

Area of application

The dimensions of 1800×1100×600 mm give enough room to house main distribution boards, automation panels, power switching equipment and communication equipment in one body. Several functional sections – metering, protection and distribution – can be arranged on the mounting panel and DIN rails, and cable routes can be laid through glands without overloading the internal space.

The wall mounting and the insulated body with protection rating IP54 allow the cabinet to be installed outdoors on posts, building walls and steel structures. This format is convenient where a bulky set of equipment must be installed compactly on a single support without resorting to a floor-standing panel or a separate room.

Where it is used:

• outdoor main distribution boards for power supply of buildings and structures;
• electricity metering and distribution points on posts and facades;
• automation cabinets for outdoor lighting of streets and territories;
• housing communication and telemechanics equipment at infrastructure facilities;
• control panels for pumping stations and utility systems outdoors;
• distribution points at open-type production and warehouse sites.
