Sfera ShU 1000×1500×550 IP54 cabinet

Equipment

• Galvanised steel body with polymer powder coating
• Thermal insulation – mineral wool 50 mm
• Door with a gasket around the perimeter and a lock
• Mounting panel / DIN rail
• Cable glands
• Mounting hardware kit

Basic configuration. The composition and dimensions are specified for the task – the cabinet is made to order.

Area of application

The 1000×1500×550 mm body holds several automation panels, main distribution devices, switching units, UPS, modem and network equipment on DIN rails, as well as cable entries and terminal groups. The wide mounting panel allows components to be distributed horizontally without increasing the installation depth, which is convenient with limited space next to a wall or post.

Mineral wool 50 mm and the door gasket provide thermal insulation from external temperature changes and protection from dust and moisture to class IP54, so the cabinet is placed in the open or under a canopy without additional shelter. The wall mounting and compact depth simplify installation on building facades, posts and steel structures without a foundation.

Where it is used:

• housing metering and distribution panels at outdoor power supply facilities;
• installing automation and telemechanics systems at water supply and sewage facilities;
• installing communication nodes and switching equipment along cable line routes;
• housing video surveillance and security alarm equipment at perimeter facilities;
• installing lighting control panels on streets and enterprise territories;
• installing instrumentation on open-type process sites.
