Sfera ShU 1000×1000×600 IP54 cabinet

Equipment

• Galvanised steel body with polymer powder coating
• Thermal insulation – mineral wool 50 mm
• Door with a gasket around the perimeter and a lock
• Mounting panel / DIN rail
• Cable glands
• Mounting hardware kit

Basic configuration. The composition and dimensions are specified for the task – the cabinet is made to order.

Area of application

The dimensions of 1000×1000×600 mm with a depth of 600 mm allow several power and low-voltage devices to be housed in one body: circuit breakers, contactors, relays, metering devices, terminal rows and communication modules on one or several DIN rails or a mounting panel. This volume is enough for a node combining the distribution and auxiliary equipment of one section of a network, without spreading it across separate cabinets.

The galvanised body with thermal insulation and a gasketed IP54 door allows the cabinet to be installed by wall mounting on open sites, posts and building walls, where protection from precipitation and dust matters, without heating and ventilation by default. The compact square format is convenient where a large floor-standing cabinet cannot be installed and equipment must be placed near the connection point.

Where it is used:

• electricity metering nodes at service entrances of industrial and municipal facilities;
• distribution points of outdoor lighting of streets and territories;
• automation cabinets of water supply and sewage systems on open sites;
• control posts for pumping stations and shut-off valves;
• housing communication and telemetry equipment on posts and masts;
• auxiliary power supply panels for construction and production sites.
