Sfera ShNU 1700×600×400 IP65 cabinet

Name: Sfera ShNU 1700×600×400 IP65 cabinet
Brand: Сфера
SKU: 1727
Price: 71500 RUB
Availability: PreOrder

Sfera ShNU 1700×600×400 IP65 cabinet Photo 1

Characteristics

The ShNU566 uninsulated outdoor body with external dimensions of 1700×600×400 mm is designed to house a bulky set of switching and metering equipment outdoors. This combination of height and width allows the equipment to be spread across several rows of DIN rails with room left for cable routes, and a depth of 400 mm allows devices with protruding elements to be installed without the risk of the door catching on them. The wall mounting and IP65 protection rating make the cabinet suitable for installation on building walls, posts and steel structures without a foundation.

Price: 71 500 rubles*

Catalog download

* - Цена, указанная на сайте, актуальна на момент размещения информации. Для получения актуального предложения отправьте заявку.

Description

Part number (design documentation code)	ShNU566
Overall dimensions (height × width × depth), mm	1700×600×400
Type	Uninsulated outdoor cabinet (ShNU)
Body material	Galvanised steel
Degree of protection	IP65
Mounting	Wall-mounted

Equipment

Galvanised steel body with polymer powder coating
Door with a gasket around the perimeter and a lock
Mounting panel / DIN rail
Cable glands
Mounting hardware kit

Basic configuration. The composition and dimensions are specified for the task – the cabinet is made to order.

Area of application

The dimensions of 1700×600×400 mm correspond to an increased-height cabinet for service-entrance and distribution panels, electricity metering and low-current automation. Main and group breakers, meters, relays, terminal blocks and small converters are placed on the mounting panel and DIN rails; the body depth of 400 mm leaves a reserve for connecting cables and installing devices with surface-mounted covers.

The door with a gasket around its perimeter and a lock, the cable glands and the IP65 protection rating allow the cabinet to be used in the open air – on facades, power line poles, site fences – without additional shelter. The wall-mounted version saves space during installation where floor installation is impossible or impractical, and the vertical layout is convenient for long cable entries from above and below.

Where it is used:

electricity metering points at the service entrance of buildings and structures;
distribution panels of street lighting;
automation and telemechanics cabinets at power supply facilities;
switching posts of video surveillance and communication systems;
control panels for pumping and ventilation units;
housing equipment at industrial sites and construction sites.
