Sfera ShUR-1700x1200x1200-2-2-1-IP65 cabinet
Characteristics
Placing equipment directly on an operating pipeline. The cabinet can be split either horizontally or vertically.
Dimensions
We make cabinets to order to the required dimensions. To determine the internal dimensions:
-
with thermal insulation based on mineral wool boards, assume a wall thickness of 54 mm and a door thickness of 47 mm;
-
with thermal insulation based on foamed rubber or foamed polyethylene, assume a wall and door thickness of 25 mm.
Price:
135 500 rubles*
- Description
- Equipment
| Overall dimensions (height × width × depth), mm | 1700×1200×1200 |
| Type | Insulated heated split pipe-mounted cabinet (ShTUO) |
| Body material | Galvanised steel |
| Thermal insulation material | Mineral wool thermal insulation boards (50 mm thick) |
| Degree of protection | IP65 |
| Heater type | Explosion-proof with thermostat |
| Weight, kg | 100 |
- Body made of galvanised steel. Metal thickness 1-3 mm;
- Canopy roof – 1 pcs;
- Split for a pipe with a diameter of 340 mm;
- Special eye bolts (for lifting the cabinet with a hoist) – 4 pcs;
- Triangular-key locks (+ keys) – 4 pcs;
- Thermal insulation material – mineral wool insulation boards (50 mm thick);
- Reliable fittings (hinges, locks, U-shaped door gasket);
- Set of supports 500 mm high of reinforced demountable construction;
- Door with a catch in the open position – 2 pcs;
- Convenient plastic handle on the cabinet door – 1 pcs;
- Earthing wire between the body and the door – 2 pcs;
- In the lower part of the cabinet body there are explosion-proof cable glands KV R3-TsP-15 IP68 and KV A2F20-FC with plugs – 2 set;
- OSHA-R-10 1000 W explosion-proof heater with built-in thermostat, mounted on supports in the lower part of the cabinet – 1 pcs;
- Polymer powder coating per the RAL catalogue.
- Packaging: bubble wrap + corrugated cardboard + wooden crate
